DETAIL PRODUCT
Input Voltage 3ph 380 V ± 15%
Frequency 50 / 60 Hz
No-load Voltage 60 VDC
Rated Input Power TIG : 13.6 KVA
MMA : 19.7 KVA
Rated Input Current TIG : 20.7 A
MMA : 30 A
Rated Working Voltage TIG : 10.4 – 26 V
MMA : 20.8 – 36 V
Range Of Output Current TIG : 10 ~ 400 A
MMA : 20 ~ 400 A
Rated Duty Cycle 60%
Power Factor ≥0.89
Efficiency ≥85%
Insulation Type F
Protection Type IP21S
Pulse Frequency –
Pulse Duty –
Arc Leading HF
AC Frequency –
Clean Width –
Up Slope 0 ~ 10 S
Down Slope 0 ~ 10 S
Post-Flow Time 0 ~ 10 S
Pre-Flow Time –
Weight 22 Kg
Dimension (LxWxH) 510 x 240 x 410 mm

STANDARD ACCESSORIES
TIG Torch WP 18 4 m
Earth Clamp... Read More DETAIL PRODUCT
Input Voltage 3ph 380 V ± 15%
Frequency 50 / 60 Hz
No-load Voltage 60 VDC
Rated Input Power TIG : 13.6 KVA
MMA : 19.7 KVA
Rated Input Current TIG : 20.7 A
MMA : 30 A
Rated Working Voltage TIG : 10.4 – 26 V
MMA : 20.8 – 36 V
Range Of Output Current TIG : 10 ~ 400 A
MMA : 20 ~ 400 A
Rated Duty Cycle 60%
Power Factor ≥0.89
Efficiency ≥85%
Insulation Type F
Protection Type IP21S
Pulse Frequency –
Pulse Duty –
Arc Leading HF
AC Frequency –
Clean Width –
Up Slope 0 ~ 10 S
Down Slope 0 ~ 10 S
Post-Flow Time 0 ~ 10 S
Pre-Flow Time –
Weight 22 Kg
Dimension (LxWxH) 510 x 240 x 410 mm

STANDARD ACCESSORIES
TIG Torch WP 18 4 m
Earth Clamp Set 3 m
MMA Electrode Holder Set 3m
Gas Hose 2m
Hose Clip


GARANSI RESMI 1 TAHUN... Read Less
